2PC High Vacuum Ball Valve Semiconductor Pharmaceutical

Customer's inquiry form can be directly dialed +86 (577) 86838999 to the marketing department,
or sent to the corporate email pioneertrade@163.com
Specific agreement: delivery date, whether to include tax, payment method and special requirements, etc.
Customers provide: working pressure, temperature, medium, connection method and other detailed parameters

Address: No.116 Binhai 11th Road, Jinhai 2nd Road, Longwan Konggang New District, 325000 Wenzhou China
Phone: +86 (577) 86838999
Fax: +86 (577) 86911098
Enterprise email: pioneertrade@163.com

Status de disponibilidade:

Quantidade:



Inquérito

Product Description

Product Description

High vacuum ball valve available for manual operation or ISO5211 direct mounting platform apply to pneumatic and electric control, makethe actuator easy installed, and products more beautiful.It has a high flow conductance and the connection characteristics of various forms, used in high vacuum or general pressure conditions.

Widely use in the dairy products, wine, biotechnology, food & beverage, pharmaceutical, chemical, cosmetics and new energy industry, semiconductor industry etc.

Scope Of Application	16×10⁵~6.7×10^-4Pa("G" Thread) 6×10⁵~6.7×10^-4Pa(Loose Flange) 40×10⁵~6.7×10^-4Pa(Weld) 10⁵~6.7×10^-4Pa("KF" Fast Release Flange)
Valve Leakage Rate	≤6.7×10^-5Pa.L/S.
Medium Temperature	-25~+150ºC (PTFE) -30~+260ºC (PPL)
Installation Status	Any
Body、Bonnet、Stem、Ball	Stainless Steel
Seal	Viton (optional)、PTFE、PPL
